Description
ELP 8mp High Speed Mini sony IMX179 cctv HD USB Board Camera Module with 3.7mm megapixel lens for Android/Linux/Windows
1) 8mp High resolution , suitable for document capture
2) Advanced Sony (1/3.2” ) image sensor .
3) High quality 3.7mm lens
4) Support OS: Win XP\Win7\Win8\Android\Linux (Eight-core computer configuration ), support raspberry pi
5) Picture format : MJPEG&YUY2
|
Sensor Type:
|
Sony (1/3.2”) IMX179
|
|
Active Array Size :
|
3264X2448
|
|
Lens
|
3.7mm lens(other lens optional)
|
|
Minimal illumination :
|
0.5Lux
|
|
Maximum Image Transfer Rate :
|
3264X2448 MJPEG 15fps YUY2 2fps
2592X1944 MJPEG 15fps YUY2 3fps 2048X1536 MJPEG 20fps YUY2 3fps 1600X1200 MJPEG 20fps YUY2 10fps 1280X960 MJPEG 20fps YUY2 10fps 1024X768 MJPEG 30fps YUY2 10fps 800X600 MJPEG 30fps YUY2 30fps 640X480 MJPEG 30fps YUY2 30fps |
|
module Size :
|
38mm * 38mm /32mm * 32mm
|
|
Temperature (Operation) :
|
-20degree to 70 degree
|
|
Temperature (Stable Image):
|
0 degree to 60°degree
|
|
Camera Board Assembly technique :
|
SMT (ROSH)
|
|
Focus :
|
Fixed
|
|
Object distance:
|
5CM-100M
|
|
Resolution :
|
600LW/PH (Center)
|
|
Interface :
|
USB 2.0 High Speed
|
|
protocol :
|
USB Video Class(UVC)
|
|
Power :
|
USB bus power
|
|
Operating system request:
|
Win XP\Win7\Win8\Android\Linux\Mac OS
|
|
Certifications :
|
FCC and CE
|
|
S/N Ratio :
|
44dB
|
|
Dynamic Range :
|
83.5dB
|
|
Shutter :
|
Rolling shutter/ frame exposure
|
|
IR Filter :
|
650±10nm
|
|
AGC/AEC/AWB/ABF :
|
Auto
|
|
Output Formats :
|
YUYV/MJPEG
|
|
IR CUT
|
SUPPORT
|
|
Adjustable parameters
|
Brightness Contrast Hue Saturation Sharpness Gamma White
|
|
USB Cable
|
1M(2M/3M/5M Optional)
|
