Description
ELP Sony IMX179 8MP Surveillance USB Camera 3264X2448 High Resolution MJPEG/YUY2 with 2.8mm lens
Features
1. 1/3.2 inch Sony IMX179 USB webcam, Undistortion Lens
2. 8 megapixel high resolution Mjpeg USB camera
3. UVC usb camera, Support windows, linux, Mac with UVC, also for android system.
Compatible with raspberry pi, Ubuntu, Opencv, Amcap and many other USB web camera software and hardware.
4. Webcam USB with 2.8mm lens
5. 41*41mm mini micro usb Box camera
6. USB webcam, well used in many machines, atm machine, medical machine, automatic vending machine, industry machine..
7. USB camera module Parameters changable (Brightness, Contrast, Saturation, White Balance, Gamma, Definition, Exposure…)
Spcifications
Model: ELP-USB8MP02G-BL28 | |||
Resolution & frame |
3264X2448 @ 15fps / 2592X1944@ 20fps 2048X1536 @ 20fps / 1600X1200@ 20fps 1280X960 @ 20fps / 1024X768@ 30fps 800X600 @ 30fps / 640X480@ 30fps |
||
Sensor | SONY IMX179 | Compression format | MJPEG / YUV2(YUYV) |
Lens Size | 1/3.2inch | Lens Parameter | M12 2.8mm lens |
Pixel Size | 1.4um | Board size/Weight | 41*41mm,about 0.3kg |
image area | 6.18mm x 5.85mm | Connecting Port type | USB2.0 High Speed |
Max. Resolution | 3264(H) X 2448(V) 8Megapixel | Free Drive Protocol | USB Video Class(UVC) |
S/N Ratio | 34dB | OTG protocol | USB2.0 OTG |
Dynamic Range | 72.5dB | Shutter Type | Rolling shutter /
Frame exposure |
Sensitivity | 0.65V/lux-sec@550nm | AEC,AEB,AGC | Support |
Mini illumination | 0.5lux | Button Camera | Support |
Operating Voltage | DC5V | Working temperature | -10~70 degree |
Working current | 150mA~240mA | Storage temperature | -20~85 degree |
Adjustable
parameter |
Brightness, Contrast, Saturation,
Sharpness, Gamma, Gain, White balance, Hue, Backlight Contrast, Exposure |
LED board control interface | Support 2P-1.25mm socket |
LED board power connector | Support 2P-2.0mm socket | ||
Support OS | WinXP/Vista/WIN7/WIN8 /WIN10 Linux with UVC Mac-OS X 10.4.8 or later Wince with UVC, Android 4.0 or above |
